Reentry around an anatomical obstacle has been named anatomic reentry as compared to functional reentry. Cox et al. who developed the surgical treatment for atrial fibrillation observed that chronic atrial enlargement causes atrial fibrillation. The concept of the "two holes macro-reentry" including the left atrial appendage and the pulmonary vein orifice led to the idea of creating lesions to interrupt these anatomical reentry circuits. Lower loop reentry around inferior vena cava is a variation of typical atrial flutter and upper loop reentry around superior vena cava. Other examples of anatomic reentry include scar-related VT and BBRVT. Left atrial macro-reentry circuits have also been described.
Peri-mitral atrial tachycardias develop following pulmonary vein isolation or mitral valve surgery. There have also been reports of reentrant atrial tachycardia not involving the AV node. Adenosine-sensitive atrial tachycardia has variable locations and can shift to another site after ablation. In a case reported by Inagaki mapping identified the critical slow conduction zone close to the mitral annulus. Identifying parts of the reentry circuit is essential for successful ablation maneuvers to terminate the arrhythmia.The right atrium possesses the anatomical structures that form the atrial flutter circuit.
The cavotricuspid isthmus is the narrow point between the inferior vena cava and the tricuspid annulus where typical atrial flutter can undergo ablation successfully. The terminal crest has anisotropic property and forms a functional line of a block to conduction in the right atrium. Since its first description more than a century ago, our understanding of cavotricuspid isthmus -dependent atrial flutter has significantly improved, using recent advanced ultrahigh-resolution mapping systems. A close follow-up of the patient will be suggested to detect the occurrence of atrial fibrillation . Different mechanisms of arrhythmogenesis may be responsible for initiating and sustaining atrial fibrillation.
Accepting the multiple wavelet theory as the sustaining force, Haissaguerre described ectopic foci at the point where the pulmonary veins insert into the left atrium for initiation of atrial fibrillation. This allowed for targeted radiofrequency ablation.Pulmonary vein ectopic foci show high dominant frequency giving origin to fractionated rotors. In some patients, both atrial fibrillation and atrial flutter can occur.
This clinical interrelationship may reflect an underlying common pathophysiology such as atrial fibrillation can cause a functional line of block that creates a macro-reentrant circuit and atrial flutter. On the other side atrial flutter, due to short cycle length may result in atrial fibrillation. Figure 8 Endoepicardial connection in the presence of an endocardial cavotricuspid isthmus line of block.
These technological improvements have also facilitated curative treatment with radiofrequency catheter ablation while simultaneously creating some terminological and conceptual confusion about its nature. 22 The circuit is localized in the lower right atrium, but is also CTI dependent. The circuit involves the lower right atrium, as manifested by an early breakthrough in the lower right atrium, wavefront collision in the high lateral right atrium or septum and conduction through the CTI. Alternating lower loop reentry and typical AFL or variable breakthrough sites in the lateral right atrium may result in cycle length oscillation. Of note, the left atrium and the septum are activated in a similar sequence to CCW typical AFL, giving negative atrial complexes in the inferior leads. The morphology of the flutter wave is determined by the site of the breakthrough of the wavefront at the crista terminalis.
Then, the late positive deflection seen on the flutter wave in the inferior leads during CCW typical AFL will be attenuated during lower loop reentry circuit, by abolition of these late inferiorly directed forces. The ECG shows regular flutter waves (F-waves; not to be confused with f-waves seen in atrial fibrillation) which gives the baseline a saw-tooth appearance. Atrial flutter is the only diagnosis causing this baseline appearance, which is why it must be recognized on the ECG. The flutter waves (on the contrary to f-waves in atrial fibrillation) have identical morphology .
Flutter waves are typically best seen in leads II, III aVF, V1, V2 and V3. The exact appearance of the flutter waves will depend on the location and direction of the re-entry circuit. In the most common type of atrial flutter, the re-entry loops around the tricuspid valve in a counter-clockwise direction. This yields negative flutter waves in II, III and aVF and positive flutter waves in V1 . If the re-entry has a clockwise direction, the flutter waves are positive in lead II, III, aVF and the P-waves typically have a notch on the apex.
Please note that for most clinicians it is not necessary to be able to determine the direction of the re-entry loop. Atrial flutter classically refers to the ECG pattern of an undulating wave with no electrical silence in at least one lead of the surface ECG. If the other flutter pattern may also suggest a reentrant circuit, this is indeed not specific as it may result from variable mechanisms in variable localizations . It is thus fair to say that after its long history, atrial flutter is now, by far, more than just one of a kind. Since its first description about one century ago, our understanding of atrial flutter circuits has considerably evolved. One AFL circuit can have variable electrocardiographic manifestations depending on the presence of pre-existing atrial lesions, or impaired atrial substrate.
Conversely, different atrial circuits including different mechanisms can present with a very similar surface ECG manifestation. The development of efficient high-resolution electroanatomical mapping systems has improved our knowledge about AFL mechanisms, as well as facilitated their curative treatment with radiofrequency catheter ablation. This article will review ECG features for typical and atypical flutters, and emphasize the limitations for circuit location from the surface ECG. Differentiating the mechanisms arrhythmogenesis may be difficult.
When equal PPI-TCL values are obtained for widespread points, a large macro-reentrant circuit should be suspected. Then a reentry circuit spanning left and right atrium via Bachmann bundle and Marshall ligament is possible. The bundle branch reentry ventricular tachycardia runs via a macro-reentry circuit including the His bundle and the fascicular branches. It is common in dilatative cardiomyopathy with reduced left ventricular ejection fraction. The right bundle branch is more vulnerable to unidirectional block due to a long refractory period and slow retrograde conduction via the left bundle branch. The connection between the two bundle branches forms by bridges spanning the ventricular septum.
The surface electrocardiogram will show a left bundle branch block pattern. The contrariwise BBRVT showing right bundle branch block pattern on ECG is rare. These authors also noted that septal scar was an important requisite for biatrial tachycardia together with the presence of two interatrial connections to allow for circus movement tachycardia. In the present case, the surgical scar along the septum with enlarged atria likely predisposed the patient to biatrial tachycardia.
In a normal functioning heart, electrical impulses are sent out from the sinus node in the right atrium. This node controls the heart rate and timing of heartbeats. The electrical impulses travel through the heart muscle in the atria. In atrial flutter, an abnormal electrical circuit forms in the atria. This causes abnormally frequent contractions in the upper chambers. It may cause the lower chambers of the heart to beat fast too, but often not as fast as the atria.
This often happens after some types of heart surgery, heart muscle damage, or other heart changes. Lower loop reentry atrial flutter uses a circuit that includes the CTI, as common atrial flutter, but it shortens the circuit through a gap in the crista terminalis. The mean cycle length is usually from 170 to 250 ms. Positive forces in inferior leads and V1 will be underpowered as a consequence of the change in the typical up-down depolarisation of the lateral wall. Upper loop reentry was also described using a circuit through a gap in the crista terminalis and then in the posterior right atrium wall. The electrocardiogram pattern mimics a clockwise typical flutter but the cycle length is usually shorter, as in lower loop reentry. The observant will notice that the classification differs slightly from that of atrial fibrillation.
Acute and paroxysmal cases are common in clinical practice. Thus, as compared with atrial fibrillation, atrial flutter is not capable of persisting for longer periods of time. This is due to the fact that atrial flutter is caused by a macro re-entry circuit (a large re-entry circuit) and re-entry circuits are vulnerable processes that usually self-terminate within minutes, hours or days. In the vast majority of cases, the re-entry circuit in atrial flutter is located in the right atrium and it typically loops around the tricuspid valve.
Impulses spread rapidly through the atria from this re-entry circuit. 34–36 Careful confirmation of CTI dependency of the circuit is always the first step of the procedure, using entrainment-guided-mapping techniques. In these cases, confirmation of CTI-dependency is mandatory, although it may sometimes be difficult or even misleading.
Typical counterclockwise atrial flutter, and anatomical correspondence of the flutter wave to the electrocardiographic morphology. The flutter waves are best seen during carotid sinus massage . CS, coronary sinus; IVC, inferior vena cava; SVC, superior vena cava. The excitable gap is the part of the reentry circuit between the tail of refractoriness and the next orthodromic excitation wave.
An external stimulus can enter the reentry circuit at the excitable gap. Through entrainment Waldo et al. differentiate between atrial flutter type I and II. Atrial flutter type I can be transiently entrained and interrupted by rapid atrial pacing since it is caused by reentry and has an excitable gap. Type I atrial flutter can show concealed entrainment with a zone of slow conduction.
In contrast, type II atrial flutter has not been entrained, and the mechanism remains speculative. A reentry arrhythmia is a self-sustaining cardiac rhythm abnormality in which the action potential propagates in a manner analogous to a closed-loop circuit. It is a disorder of impulse conduction and is discrete from disorders of impulse generation such as automaticity or triggered activity.
This activity reviews the presentation, evaluation, and management of reentry arrhythmias and stresses the role of an interprofessional team approach to the care of affected patients. Single-loop biatrial tachycardia around the mitral and tricuspid valves is a rare form of macro-reentrant tachycardia involving both the RA and LA that can be diagnosed by entrainment as well as activation mapping. A septal scar with the presence of two interatrial connections is required for the tachycardia to occur and ablation at the RA isthmus usually is successful in eliminating this tachycardia. In this case, termination did not occur with CTI ablation but, instead, changed to a second atrial flutter requiring a second ablation line for termination, which also eliminated RA to CS activation of the LA. The addListener() function calls setState(), so every time the Animation generates a new number, the current frame is marked dirty, which forcesbuild() to be called again.
In build(), the container changes size because its height and width now use animation.value instead of a hardcoded value. Dispose of the controller when the State object is discarded to prevent memory leaks. It is difficult to describe the F waves as positive or negative in the frontal plane, but the negative bifidity in V1 is highly suggestive of typical clockwise right atrial rotation. Mapping allows for identification of reentry circuit elements such as entry, exit, conduction barriers, bystanders, inner and outer loop, isthmus site, and zone of slow conduction . Stevenson et al. proposed a mapping site classification to guide ablation.
Radiofrequency ablation success correlated with different locations in the reentry circuit. Successful ablation targets include zones of slow conduction and exit sites. Ablation at the CTI of the single-loop biatrial flutter around the tricuspid and mitral valves would normally be expected to terminate the arrhythmia.
However, in our case, the atrial flutter changed and slowed, ultimately finding another way to reach the PCS via a posterior RA channel. Ultimately, by mapping and ablating the second RA posterior channel, the tachycardia was terminated to the sinus. This, however, also limited sinus activation to the LA via BB as evidenced by the activation of the DCS being earlier than that of the PCS. 48 Most had structural heart disease with biatrial dilation, some had been operated but none had previous right atriotomy . The surface ECG was judged identical to that of typical flutter in all but for two patients in whom polarity was positive in the inferior leads during ongoing flutter. A large lateral right atrial circuit was observed for which the participation of the crista terminalis was excluded.
Ablation was successful after creation of a line between the inferior part of the circuit and the inferior vena cava. Narayan et al. reported that atrial fibrillation due to rotor activity underwent successful ablation by targeting the center of the spiral wave. This concept is called focal impulse and rotor modulation ablation .FIRM-guided RFA is used in addition to PVI ablation and atrial tachycardia/atrial flutter ablation.
Reports of the long-term success of PVI are 50 to 60% in paroxysmal AF and less in persistent and permanent AF. Consistent with the findings of the CONFIRM trial Tomassoni et al. reported promising long-term success for FIRM-guided ablation for atrial fibrillation in addition to conventional ablation. Pericaval intra-atrial reentry tachycardia is specific to Fontan surgery with longer cycle lengths and zones of slow conduction compared to periannular IART. Both, pericaval und periannular IART are amenable to ablation.Ventricular tachycardia following repair of congenital heart disease can be traced to anatomic isthmuses and thus be successfully ablated.
Reentry describes a self-sustaining cardiac rhythm abnormality. In reentry, the action potential propagates in a circus-like closed loop manner. It is a disorder of impulse conduction and thus describes one kind of arrhythmogenesis and is differentiated from disorders of impulse generation such as automaticity and triggered activity. The pathophysiologic importance of reentry and utility as a treatment target in atrial fibrillation is part of ongoing research.
A 56-year-old man with diabetes, hypertension, and coronary disease presented with severe mitral regurgitation and underwent mitral valve replacement with coronary artery bypass grafting in April 2019. The surgeon initially performed a vertical incision in the left atrium between the right pulmonary veins and the interatrial septum in the interatrial groove (Waterston's groove). However, because of poor visualization, another horizontal incision was made in the posterior RA and included the atrial septum . Thereafter, mitral valve replacement was performed through this larger incision involving the RA, septum, and LA.
Postoperatively, the patient developed atrial fibrillation and was placed on amiodarone for several weeks and then taken off the medication. Several months later, he developed an atrial flutter as shown in Figure 2. The ECG showed a slow atrial flutter with morphology consistent with that of a typical atrial flutter.
